Atlas Electric designs, assembles and wires Power Distribution Systems to be housed in a variety of different ways to suit each customer’s unique requirements and budget. The equipment can be installed in our Prefabricated Modular E-Houses, Shipping Containers or Van Trailers. Regardless of the housing method you will have the benefit of the equipment being installed efficiently in our factory controlled environment under the direct supervision of the engineering team that designed it.
Advantages
- Lower Installation Cost
- Reduced Installation Time
- Engineer Supervised
- Easily Moved to New Location
Features and Options
- Low and Medium Voltage Switchgear
- Motor Control Centers
- Variable Frequency Drives
- Panelboards
- Interior and Exterior Lighting
- HVAC Systems
- Battery and Charging Systems
E-Houses/Containers/Trailers - Recent projects gallery
Atlas Electric Custom Manufactured E-House
- 2ea Reconditioned Square D 3000a main breaker switchboards:
- 3000a main breaker with LSIG
- 3ea 800a frame breakers with 630a trip LSI
- 1ea 800a frame breaker with 800a trip LSI
- 2ea 1600a frame breakers with 1200a trip LSI
- 4ea 800a frame breakers with 400a trip LSI
- New 150kVA Dry type transformer 480D-220Y, K-4 IP23
- New UPS Panelboard 18 Circuits, 100A, Fully Rated, 240/120V
- New Distribution panel 30 Circuits, 225A, Fully Rated, 240/120V
- New Customer Supplied Equipment to be installed in the E-House:
- ABB Motor Control Centers
- 1ea Danfoss 1250HP Variable Frequency Drives
- 2ea Danfoss 800HP Variable Frequency Drives
Connex 20’ Power Distribution Container
Connex 20’ Power Distribution Container with the installation and wiring of the following equipment:
• New Siemens 3000a switchboard, 3000a main breaker, 2ea 400a feeder breakers and 4ea 600a feeder breakers
• 2ea New Siemens 600a Main Lug panelboards
• New 12×12 N-1 Gutter
• Exterior CT Enclosure for utility supplied CTs
• Exterior Meter base for utility installed metering equipment
• Custom built 3-0 7-0 man door in barn door of container
• 5500w electric heater
Launch Pad Support Trailers
Launch Pad Support Trailers with the fabrication, installation, and integration of the following equipment and major components:
- Trailer top catwalk and railing system
- Aluminum interior walls and diamond plate floor
- Extendable catwalk lighting
- Extendable gimble mount pole for camera mounting
- Mitsubishi 3 ton air conditioning system
- 225 KVA dry transformer 12470-480Y/277 volt 3 phase
- Siemens 400 amp panelboard 480Y/277 volt 3 phase
- 75 KVA dry transformer 480-208Y/120 volt 3 phase
- High voltage incoming cabinet with load break elbows
- 400 amp generator circuit breaker
- 480 and 208 volt entry and exit cabinets on each side of trailer
- Assorted power receptacles
- Veris E51H5A Bi-directional energy meter
- Interior lighting
Rock Crushing Plant Motor Control Van
| Rock Crushing Plant Motor Control Van with the following major components: |
- Two Lineups of Reconditioned Allen Bradley 2100 Series Motor Control Center with assorted Size 1 thru Size 3 FVNR Starters, and Feeder Circuit Breakers
- Reconditioned Allen Bradley SMC Plus 400 HP Reduced Voltage Starter with Bypass Contactor
- Reconditioned Allen Bradley SMC Plus 300 HP Reduced Voltage Starter with Bypass Contactor
- New Hyundai 40 HP Variable Frequency Drive
- New GE Spectra Series 2000 Amp Switchboard 480/277 volt
- New 50 KVA Dry Transformer 480-240/120 volt and LV Panel
- New Control Tower with Custom Control Cabinet
- New Under Van Custom Motor Cable Connection Boxes
Container Housed Motor Control and Power Distribution Center
Container Housed Motor Control and Power Distribution Center with the following major equipment:
| • 40’ High Cube Container with 3’ Steel Man Doors • New GE Spectra Series 1200 Amp Main Breaker Switchboard 480/277 volt with assorted Feeder Breakers • Reconditioned Allen Bradley 2100 Series Motor Control Center with 2 each Size 3 and 3 each Size 1 FVNR starters • New Hyundai 200 HP Variable Frequency Drive • 4 each New Hyundai 30 HP Variable Frequency Drives • 2 each New Stop Start Control Consoles (one for parallel field installation) • New 1000 KVA MGM Dry Step- Up Transformer 480D-4160Y/2400 and 5 KV 200 Amp Fusible Load Interrupter Switch • New Neutral Grounding Resistor 4160/2400 with Startco SE 325 NGR Monitor and RK 325 Remote Reset • 15 KVA Dry Transformer 480-240/120 volt with LV Panel |
New Surplus E-House
Equipped with 15KV 1200 amp ABB SafeGear Metal Clad Arc Resistant Switchgear.
The switchgear includes AMVAC 1200 amp circuit breakers with a Main-Tie-Main configuration, 13ea. feeder circuit breakers and prepared cells for the future addition of 2 more feeder breakers. The E-house also has space and provisions to add up to two more sections of switchgear with 4 more feeder breakers. Additional features include complete insulation package with R-11 thermal resistance rating, wall mount HVAC system, and a fully equipped control battery room. Atlas Electric can reconfigure and customize this E-House and/or Switchgear to suit your application.
Atlas Electric repurposed one half of a double wide New Surplus E-House
Atlas Electric repurposed one half of a double wide New Surplus E-House by removing the original 15 KV switchgear as well as the switchgear rear access doors and fabricating two new insulated walls to close in the access doors and open side. We then installed two 5-ton wall mount air conditioning units with 10 KW of heat, reinforced custom service door, three windows, lighting system, smoke detectors, ceiling fan and cable tray. Additionally, we installed and wired customer supplied equipment including VFD’s, Allen Bradley MCC, PLC cabinet, lighting and heat trace distribution boards, panels and UPS.
Atlas Electric still has the other half of this E-House that can be repurposed and customized to suit your application!
Trailer/Container Housed Power Distribution Center
Trailer/Container Housed Power Distribution Center with the following features and major components:
- 40” Dual Axle Trailer with Handrailing around each end of trailer
- 20’ High Cube Container with formed metal interior walls, ceiling, and 3” Roxul insulation
- 3’x7’ Fire proof metal door with panic hardware and closing device
- Atlas Electric Medium Voltage 600 amp 5 KV Switchgear lineup with a non-fused main load break switch, 3 each Toshiba HV6AS-L manually operated circuit breakers, SEL 751 feeder protection relays, Becker SMC D-4000-1 High voltage monitor, capacitor trip device, Benshaw 600 HP 4160 volt Soft Start, load side 5 KV receptacles
- Bard wall mount 5 ton AC unit with 9 KW heat
- 15 VKA Dry Transformer 4160-208/120 volt with load center and Interior/exterior lighting package
Power Distribution Center (E-House)
Power Distribution Center (E-House) with the integration of the following major components: Siemens 2000 amp Service Entrance Switchboard 480Y/277 volt, Benshaw 600HP Soft Start, Benshaw 100HP Soft Start, 5 KVA Transformer 480-120/240 volt, LV Panel, two each Control Cabinets, 7.5 KVA Control Power Transformer, 2 ton HVAC unit.
Four each 20’ High Cube Containers
Four each 20’ High Cube Containers with the following equipment installed and wired for a Temporary Power Distribution Project:
- Siemens 4000 amp Main Breaker Switchboard, 480Y/277 volt three phase, service entrance rated
- Utility Meter Socket
- Two each Siemens Panelboards 400 amp 480Y/277 volt three phase.
- Siemens 225 KVA Dry Transformer 480-208Y/120 volt three phase.
- Three each Siemens 400 amp 120Y/208 volt Panels
- 2 each Steel Man Doors with Panic Hardware
- Interior Lighting, Heat, and 120 volt Receptacles
- Assorted Outdoor Receptacles
Rock Crushing Plant Custom Motor Control Container
Rock Crushing Plant Custom Motor Control Container with the following features:
- Interior insulated, framed and sheeted with formed steel panels
- Operator room doors and windows
- Custom control console
- Reconditioned Allen Bradley Motor Control Center
- Warning siren
- 5 ton HVAC unit
- Incoming Cable J-Boxes
- Small motor receptacles
- Large motor termination boxes
Shipping Container housed Power Distribution Center
Shipping Container housed Power Distribution Center with the following major components:
- Atlas Electric custom manufactured 5 KV, 1200 amp switchgear with a main non-fused load interrupter switch, 5 each Becker SMC 600 amp vacuum circuit breakers, 5 each Schweitzer 751A feeder protection relays, 5 each PEMCO PEM 579 high voltage ground check relay
- Remote vacuum circuit breaker control cabinet
- MGM 225 KVA dry transformer 4160-480Y/277 volt
- Square D 400 amp, 480Y/277 volt panelboard
- 15 KVA dry transformer 480-240/120 volt and LV panelboard
- 3’x7’ steel man door
- 2 each forced air heaters
- Interior lighting
Custom Manufactured Power Distribution Center (E-House)
Custom Manufactured Power Distribution Center (E-House) with the installation and integration of the following major components:
- Atlas Electric 5 KV Metal Enclosed Switchgear with 1 each Combination Non Fused Load Interrupter Switche/GE Power-Vac 1200 amp Circuit Breakers and 1 each Non Fused Load Interrupter Switch. Control components included a Schweitzer SEL-751A Feeder Protection Relay.
- Allen Bradley Centerline Medium Voltage Motor Control Center with 4 each 400 amp contactors.
- Two each Allen Bradley PowerFlex 7000, 5 KV, 1050 KW Variable Frequency Drives.
- Two each Allen Bradley PowerFlex 7000, 5 KV, 1600 KW Variable Frequency Drives.
- Allen Bradley Arcshield Centerline 2100 IntelliCenter Low Voltage Motor Center.
- General Electric Spectra Series Power Panelboard, 600 amp, 480/277 volt.
- 25 KVA Dry Transformer 480-120/240 volt and Distribution Panel.
- Two each Carrier 25 Ton HVAC units roof mounted with Amana 12000 BTU Heat Pump.
- Allen Bradley Programmable Logic Controller.
Custom Manufactured Power Distribution Center (E-House)
Custom Manufactured Power Distribution Center (E-House) with the installation and integration of the following major components:
- Atlas Electric 5 KV Metal Enclosed Switchgear with 2 each Combination Non Fused Load Interrupter Switches/GE Power-Vac 1200 amp Circuit Breakers and 1 each Non Fused Load Interrupter Switch. Control components included Startco Ground Fault Ground Check Monitors and Schweitzer SEL-751A Feeder Protection Relays
- Allen Bradley Centerline Medium Voltage Motor Control Center with 2 each 400 amp contactors.
- Two each Allen Bradley PowerFlex 7000, 5 KV, 650 KW Variable Frequency Drives.
- Allen Bradley Arcshield Centerline 2100 IntelliCenter Low Voltage Motor Center.
- General Electric Spectra Series Power Panelboard, 800 amp, 480/277 volt.
- 25 KVA Dry Transformer 480-120/240 volt and Distribution Panel.
- Two each Aaon 10 Ton HVAC units roof mounted with Amana 12000 BTU Heat Pump.
- Allen Bradley Programmable Logic Controller.
Reconditioned E-House
Reconditioned E-House with the following modifications and equipment installed:
- Reconditioned Allen Bradley Motor Control Center with New VFD’s and Soft Starts
- GE Spectra Series 2500 amp Switchboard
- Siemens 5KV 800KW Variable Frequency Drive
- 10 ton wall mount HVAC unit
- 45 KVA Dry Transformer 600-208Y/120 volt with distribution panel
Container Housed Power Distribution Center
Container Housed Power Distribution Center with the following features and integration of major components:
- Interior Insulated, Framed, and Sheeted with Formed Steel Panels
- Interior Wall with Door
- Exterior Fireproof Door with Window and Panic Hardware
- 2 each Eaton Ampguard 1500 HP, 5 KV, Solid State Reduced Voltage Starters with output wired to TJB Receptacles
- GE Spectra Series 1200 Amp 480 volt Main Breaker Switchboard with large assortment of feeder Circuit Breakers wired to Cooper and Appleton Receptacles
- 2 each 5 Ton Wall Mounted HVAC Units
- 100 KVA Dry Transformer 480-380Y/220 volt connected to a Distribution Panel
- 45 KVA Dry Transformer 480-208Y/120 volt connected to a Lighting Distribution Panel
- Interior Lighting including Exit Lighting, and Emergency Lighting
Crushing Plant Custom Motor Control Power Distribution Container
Crushing Plant Custom Motor Control Power Distribution Container with the following major components and features:
- Reconditioned Allen Bradley Motor Control Center
- Interior Control Room Partition and Door
- Control Room Windows and Exterior Door
- Control Console
- LV Transformer and Distribution Panel, Lighting, and Area Heaters
- Motor Cable Receptacle Termination Box
Power Distribution Center
Power Distribution Center with the following equipment and features:
- Square D Motor Control Center equipped with a 1000 amp Main Circuit Breaker, UL Service Entrance Rating, PM 820 Power Meter, 2 ea. 30 amp Feeder Circuit Breakers and Altivar 71 200HP Variable Frequency Drive and Line Reactor
- 25 KVA Dry Transformer 480-120volt and low voltage distribution panel
- Interior and Exterior Lighting
- 24” cable tray above MCC
- 3 Ton Wall Mount HVAC Unit
- Wall and Ceiling Insulation
Container Housed Power Distribution Center
Container Housed Power Distribution Center using a Reconditioned Insulated Refrigeration Container with the following modifications, major component installation, and associated wiring:
- Siemens 800 amp Main Fused Disconnect N-3R
- Reconditioned Westinghouse 5-Star Motor Control Center with several New Hyundai VFD’s
- Exterior Man Door and Control Room Windows
- Interior wall and door separating control and MCC rooms
- 25 KVA Dry Transformer, lighting panel, and interior lighting
- Custom Control Consoles
- Two Wall Mount HVAC Units
- 1/8 “ Steel Floor Plate
Custom Manufactured E-House with GE PowerVac 15KV Switchgear
Custom Manufactured E-House with General Electric PowerVac 15KV Metal Clad Switchgear. The Switchgear lineup included six each 1200 amp vacuum circuit breakers, two each 15 KV 600 amp Load Break Switches, GE Multilin Transformer Feeder management relay, 2 each Schneider ION 7550 revenue meters. The E-House also included 30 KVA Station Services Transformer, 48VDC battery system, HVAC System, Interior and Exterior Lighting.
Skid Mounted Power Distribution Center
Skid Mounted Power Distribution Center with the following major components and associated wiring: 5 each 600-1000 Amp General Electric Spectra Series Switchboards, 4 each Yaskawa 250-400 HP Variable Frequency Drives, and 4 each Drive Isolation Transformers. Additionally the skid included an E-House containing a COMSYS Active Dynamic Filter, 30 KVA Dry Transformer 480-208/120 volt, UPS System, and low voltage distribution panel
Container Housed Power Distribution Center
Container Housed Power Distribution Center using an insulated Refrigeration Container with the following major components and associated wiring: 2500 Amp General Electric Spectra Series Main breaker Switchboard, 2 each Danfoss 600 HP Variable Frequency Drives, 2 ea. MTE Matrix Harmonic Filters, 2 ea. MTE Load Reactors, 100 HP Solid State Reduced Voltage Starter, 2 each 5-Ton wall mount HVAC units, 30 KVA dry transformer and lighting panel.
Outdoor Walk in E-House
Outdoor Walk in E-House with Atlas Electric 7.2 KV Switchgear Lineup that included 3 each Eaton Cat. No. 72T-VACT40-1250 Draw-out Vacuum Circuit Breakers, GE Multilin 350 overcurrent relays, 5 KVA CPT, Batteries and Charger. The E-House also included R-12 wall and ceiling insulation, a cooling and ventilation system and was designed to fit inside a High Cube Container for shipping overseas.
Reconditioned E-House
Reconditioned E-House with the following New equipment installed and wired: General Electric 2500 amp Main Breaker Switchboard, General Electric 800 amp Main Breaker Switchboard, Provisions for field installation of Automatic Transfer Switch, HVAC System, interior and exterior lighting.
Customized Container for Rock Crushing Plant
Customized Container for Rock Crushing Plant included installation of the following: doors, windows, interior wall, operator control console, reconditioned Cutler Hammer Motor Control Center, Stacker Custom Control Cabinet, rear access cable termination provisions, 25 KVA dry transformer, lighting panel, electric heat and lighting.
Continuous Miner E-house
Continuous Miner E-house with ABB 600 amp 5 KV Fused Load Break Switch, 3 each 5 KV Fused Load Break Switch, 3 each Allen Bradley 400 HP 5 KV Vacuum Starters, 1300 KVA Olsun Dry Transformer 4160-995/575 & 480/277 dual secondary voltages, 2 each Neutral Grounding Resistors, Allen Bradley Bulletin 2100 Motor Control Center, 100 KVA Transformer and Lighting Panel, PLC Cabinet and Air Conditioning.
Portable Mining Process Control Container
Portable Mining Process Control Container fitted with a Reconditioned Westinghouse Motor Control Center, 22 each New Hitachi Variable Frequency Drives, Motor Control Receptacles, New Custom Control Console, 15 KVA transformer and low voltage panel.
Custom Manufactured E-House
Custom Manufactured E-House containing a 5KV GE Power-Vac Lineup consisting of 7 each VB1-13.8-500-3 Vacuum Breakers and GE Multilin relays, 125 VDC batteries and battery charger, and a wall mount heating/ air conditioning unit.
Mining Compressor Area Control Container
Mining Compressor Area Control Container includes New GE 4000 amp Spectra Series Switchboard, 600 KVAR Automatic Capacitor Bank, Fire Alarm Control Panel, 75 KVA Transformer, LV Panel, Lighting Contactors and Air Conditioning.
Main Distribution Container
Main Distribution Container with 5 KV and 22 KV Lineups of ABB ZX- Switchgear. The 5 KV Switchgear included an 800 amp main and 2 each 800 amp main and 2 each 800 amp main feeder SF6 Gas Insulated Vacuum Circuit Breakers. The 22 KV Switchgear included an 800 amp and 4 each 800 amp feeder SF6 gas Insulated Vacuum Circuit Breakers. The Container also included lighting and distribution panels, fire alarm control, air conditioning, switchgear batteries and charger.
Portable Rock Crushing Plant Control Van
Portable Rock Crushing Plant Control Van with Allen Bradley Motor Control Center, Operator Control Console, PLC, Motor Cable Receptacles, Lightning Transformer and Panel.
Portable Rock Crushing Plant Control Van
Portable Rock Crushing Plant Control Van Includes Service Entrance Switchboard, Allen Bradley Motor Control Center Pop-up Operator Control Tower with PLC automation, deck railing and stairs, low voltage lighting transformer and panel.
